Product Detail

h.265 dvb-s2 SX9

Detail


Specification:System and Memory:Product Photo:
●Fully comply with DVB-S/S2/SX、, MPEG-2/4 H.264, HEVC/H.265 Standard
● Support EPG, display present / next TV Program / 7 days EPG
●Support up to DiSEqC 1.0 / 1.1 / 1.2 & USALS
●PAL & NTSC Auto Switch
● Parent control
● Support Favorites Group
● Auto scan / TP scan / Blind scan
●Support Teletext / Subtitle
●Selectable output for 1080P, 1080i, 720P and 576P format
●User-friendly remote control with colored function buttons
●USB for SW upgrade, multimedia files playback & PVR
●Unicable Support
●Support Cas(optional)
●BISS (optional)
●IPTV Protocol (optional)
●Wifi Built-in
●3G, YouTube, IPTV (optional)		● Main Processor: Montage M88CS8051B-T000
● Flash Memory: 8 MB
● DDR II: 1G (Built-in Mainchipset)
Video Decoder
Video:
● HEVC/H.265 MP@level 4.1 High tier
− MPEG-2 MP@ML/HL
− H.264 BP (with no ASO/FMO), MP& HP@ L3/L4.1
− MPEG-4 SP Profile, Advanced Simple Profile
● Video resolution:
   1080P, 1080i, 720P and 576P
● Aspect Ratio: 4:3, 16:9
Audio:
MPEG-1/2 Layer I/II/III
− Dolby AC3/AC3+ (optional)
− DRA 2 CH/5.1 CH (optional)

Demodulator:
● Demodulation:
QPSK, 8PSK, 16APSK & 32APSK
Connetcor:
Tuner:General Data:
● F Type: LNB Input * 1
● USB 2.0 *1
● mini IR
● HDMI Output
● DC IN (12V 1.0A adapter)
● Front End: DVB-S2 M88TS6011
● Input Frequency Range:   950 ~ 2150MHz
● RF input Signal Level:   -80 ~ -25 dBM
● Input Voltage range:
   100~240V 50~60Hz
● Adapter output:
   DC 12V 1.0A
● Power Consumption:
   Max 12W (Working)
● Stand-by mode: Max 0.5 W (Standby)
Standard Packing Accessories
Packing Size:Loading Quantity (pcs)
ItemQty.Product size:96X28X200mm20" GP40" GP40" HQ
Remoete control1 pcGift Box:



User Manual1 pcCarton Box:
Qty/Ctnpcs
